Oracle Exalogic Elastic Cloud Owner's Manual page 327

Note:
For more information on setting up CHAP authentication between the
compute node and storage, see the "Setting Up CHAP Authentication" topic in
the following document:
server-storage/sun-unified-storage/documentation/iscsi-
quickstart-v1-2-051512-1641594.pdf
From the Network interfaces list, select the interface that corresponds to your
9.
InfiniBand partition. You can identify the interface by logging in to the storage
appliance and running configuration net interfaces show. If there are no
partitions defined, identify the interface for the label IB_Interface.
Click OK.
10.
You can add the iSCSI target to an iSCSI target group by dragging and dropping
11.
the target to a iSCSI target group in the iSCSI Target Groups panel on the right. If
required, you can create a new iSCSI target group by dragging and dropping the
target to the top of iSCSI Target Groups panel on the right.
F.3.1.2 Create an iSCSI Initiator
You can create an iSCSI initiator by doing the following:
Before you can create an iSCSI initiator, you must identify an initiator IQN. The
1.
initiator IQN is a unique reference number associated with a specific compute
node. To find the initiator IQN for a compute node, do the following:
Log in to an Exalogic compute node.
a.
Run the iscsiadm list initiator-node command as follows:
b.
# iscsiadm list initiator-node
Initiator node name: iqn.1986-03.com.sun:01:e00000000000.51891a8b
Initiator node alias: el01cn01
Login Parameters (Default/Configured):
Authentication Type: NONE
RADIUS Server: NONE
RADIUS Access: disabled
Tunable Parameters (Default/Configured):
Configured Sessions: 1
In this example, the initiator IQN is:
iqn.1986-03.com.sun:01:e00000000000.51891a8b
Log in to the storage appliance BUI as the root user.
2.
Click the Configuration tab.
3.
Click SAN.
4.
Click Initiators.
5.
http://www.oracle.com/technetwork/
Header Digest: NONE/-
Data Digest: NONE/-
Max Connections: 65535/-
Session Login Response Time: 60/-
Maximum Connection Retry Time: 180/-
Login Retry Time Interval: 60/-
Create a Solaris Zone
Manage Solaris Zones on Exalogic F-3
