Oracle Exalogic Elastic Cloud Owner's Manual page 154

Set Up Ethernet Over InfiniBand (EoIB) on Oracle Solaris
10.128.21.186 leaf:1" enhanced port 0 lid 14 lmc 0
. . .
Switch : 0x0010e00b6d80c0a0 ports 36 "SUN IB QDR GW switch el01sw-ib03
10.128.21.187 leaf:2" enhanced port 0 lid 15 lmc 0
The lid and port data from the previous command output matches the following
switches:
•
•
The following is an extract of the third and last command:
root@el01cn16:~# ibstat
. . .
With this information you can see that 0x0021280001eff369 is the port GUID
for net4 and 0x0021280001eff36a is the port GUID for net5 (see 6). Now you
can determine the following mappings:
•
•
Run the following commands to create the EoIB datalink over net4 and display
8.
the results of the procedure:
root@el01cn16:~# dladm create-eoib -l net4 -g el01sw-ib03 -c 0A-ETH-1 eoib0
root@el01cn16:~# dladm show-eoib
LINK
eoib0
Open another terminal and log in as root to the switch net4 is connected to
9.
(el01sw-ib03 for this example).
Run the following commands to create a VNIC with no VLAN tag and display the
results of the procedure. The following is an example of the commands' output:
[root@el01sw-ib03 ~]# createvnic 0A-ETH-1 -guid 0021280001EFF369 -mac
80:C0:A0:09:16:01
vNIC created
[root@el01sw-ib03 ~]# showvnics |grep cn16
105 WAIT-IOA
80:C0:A0:09:16:01 NO 0xffff 0A-ETH-1
10-14 Oracle Exalogic Elastic Cloud Machine Owner's Guide
switch lid 14, base lid 72 matches el01sw-ib02
switch lid 15, base lid 71 matches el01sw-ib03
Port 1:
. . .
Base lid: 71
. . .
Port GUID: 0x0021280001eff369
Link layer: IB
Port 2:
. . .
Base lid: 72
. . .
Port GUID: 0x0021280001eff36a
Link layer: IB
port1 -> net4 -> el01sw-ib03
port2 -> net5 -> el01sw-ib02
GWNAME GWPORT
el01sw-ib03 0a-eth-1 506 aH---- 10000 0:0:0:0:0:0
N 0021280001EFF369
GWID FLAGS SPEED MACADDRESS
el01cn16 EL-C 192.168.10.16 0000
OVER
net4
