Parts For Oracle Server X5-2 Compute Nodes; Replacement Parts For Oracle Server X5-2 Compute Nodes - Oracle Exalogic Elastic Cloud Owner's Manual

Table D-6
Part
Number
7042768
F542-0330
F375-3609
F375-3606
F511-1496
F300-2233
F541-2732
For more information, see the
D.7 Parts for Oracle Server X5-2 Compute Nodes
Table D-7
the Exalogic machine.
Table D-7
Part Number
7089073
7094132
7078072
7067728
7095106
7097205
7085209
7083433
7083430
(Cont.) Replacement Parts for Sun ZFS Storage 7320 appliance
Description
500GB 10K 2.5 inch SATA HDD (Silver Marlin Bracket, OS
drive)
512GB SSD, 2.5" SATA Marlin bracket (ReadZilla) (FW-
AGXA0201)
8 Port LSI SAS-2 6G HBA
Dual port 4X QDR InfiniBand PCI-E HCA (CX1)
Generation 2 Cluster Heatbeat PCI-E Card
PS,AC,A247,F,12V,760W
DVD Drive Bay Panel
Sun ZFS Storage 7x20 Appliance Customer Service Manual.
lists the replaceable parts for the Oracle Server X5-2 compute nodes used in
Note:
All replacement parts shown in the following table are considered FRU when
covered under Premier Support of Systems warranty.

Replacement Parts for Oracle Server X5-2 Compute Nodes

Description
FAN MODULE
SSD, 400GB ME, 2.5" SAS3, Marlin
DIMM, 32GB, DDR3, 1600, 4Rx4, 1.35V
HEAT SINK CPU 1U
CPU, E5-2699, 2.3G, 145W, 18C
ASSY, 2.5 DISK BP
ASY, 12G SAS RAID HBA, INT, 8P
ASSY, RISER, DOUBLE_STACK
ASSY, RISER

Parts for Oracle Server X5-2 Compute Nodes

Coverage
under Basic
Warranty
FRU
FRU
FRU
FRU
FRU
FRU
FRU
Coverage with
Basic Warranty
FRU
FRU
FRU
FRU
FRU
FRU
FRU
FRU
FRU
Replacement Units D-7
