Set Up Ethernet Over InfiniBand (EoIB) on Oracle Solaris
h.
i.
10.3.2 Set Up Ethernet Over InfiniBand on Oracle Solaris 11.2
To set up Ethernet over InfiniBand connectivity for Exalogic compute nodes running
Oracle Solaris 11.2 Base Image of EECS 2.0.6.2.0 perform the following procedure:
Use an SSH client, such as PuTTY, to log in to a compute node as root. For this
1.
example log in to el01cn16 as root.
Run the following command to verify that the image version is EECS 2.0.6.2.0 or
2.
greater, and the kernel version is SunOS 11.2.
root@el01cn16:~# imageinfo
A section of the output of this command is as follows:
Exalogic 2.0.6.2.0 (build:r240216)
Image version
. . .
Kernel version
. . .
Get the names of the InfiniBand (IB) datalink by running the following command:
3.
root@el01cn16:~# dladm show-phys
The following is a section of the output of the command that displays net4 and
net5 as the names for the IB datalink:
LINK
. . .
10-12 Oracle Exalogic Elastic Cloud Machine Owner's Guide
e101cn02# ipadm create-addr –T static –a local=10.100.44.68/22 bond1/v4
Verify that your bonded interface is up, by running the following command:
hostname# ipadm show-if
IFNAME CLASS STATE
lo0 loopback ok
net0 ip ok
net4 ip ok
net8 ip down
net9 ip down
bond0_0 ip ok
bond0_1 ip ok
bond1 ipmp ok
eoib1 ip ok
eoib0 ip ok
Verify that your bonded interface was given an IP address by running the
following command:
# ipadm show-addr
ADDROBJ TYPE
lo0/v4 static
net0/v4 static
net4/v4 static
bond0/v4 static
bond1/v4 static
bond1/v4a static
lo0/v6 static
net0/v6 addrconf ok
: 2.0.6.2.0
: SunOS 11.2
MEDIA
ACTIVE OVER
yes --
yes --
yes --
no --
no --
yes --
no --
yes eoib1 eoib0
no --
yes --
STATE ADDR
ok 127.0.0.1/8
ok 138.3.2.87/21
ok 169.254.182.77/24
ok 192.168.14.101/24
ok 138.3.48.35/22
ok 138.3.51.1/22
ok ::1/128
fe80::221:28ff:fed7:e944/10
STATE SPEED DUPLEX DEVICE
