Click the Remote Control tab, and click Launch Remote Console.
4.
The remote console is displayed.

7.6 Connect to ILOM via a Serial Connection

You can connect to ILOM via a serial connection if you are unable to access ILOM via
the network due to any of the following problems:
• Misconfiguration of the network
• Misconfiguration of ILOM IP addresses
• Misconfiguration of Cisco Ethernet switch ports
• Sideband configuration issues

7.6.1 Connect to the ILOM of a Compute Node

To connect to ILOM of a compute node in the Exalogic machine using a serial
connection, complete the following steps:
Attach a serial cable from a terminal or a PC running terminal emulation software
1.
to the SER MGT port of an Exalogic compute node. The cable should be of length
15 feet or less.
Verify that your terminal or laptop is operational.
2.
Configure the terminal device or the terminal emulation software to use the
3.
following settings:
•
•
•
•
Verify that power is supplied to either PSU.
4.
If there is power applied to either PSU, then ILOM will be functional regardless of
the power state of compute nodes.
Press Enter on the terminal device. A connection between the terminal device and
5.
the ILOM is established.
The ILOM login prompt is displayed.
Log in to the CLI using the default user name root.
6.
The ILOM default command prompt is displayed.
Note:
You can reconfigure network access after connecting to ILOM via a serial
connection. For more information, see
8N1: eight data bits, no parity, one stop bit
9600 baud (default, but can be set to any standard rate up to 115200)
Disable software flow control (XON/XOFF)
Disable hardware control
Connect to ILOM via a Serial Connection
Reconfigure the Network
Set Up ILOM on the Compute Nodes 7-5
Access.
