Oracle Exalogic Elastic Cloud Owner's Manual page 269

Network Specification
Considerations
Did you complete all the networking
worksheets, which is included in
Network Configuration Worksheets,
and provide it to your Oracle
technical representative?
Have you received the site-specific
installation template from your
Oracle technical representative?
Did you review the installation
template and consult with your
Oracle technical representative
regarding site-specific changes, if
any?
Did you verify the IP addresses in the
installation template are currently not
in use?
Have you performed the required
configuration within your network
infrastructure to allow the Exalogic
machine to use the IP addresses
specified in the template?
Have you registered IP addresses in
the installation template with DNS?
Did you run the required network
cables from your network equipment
to the location where the Exalogic
machine will be installed?
Did you label the network cables that
will connect to the Exalogic machine?
Note:
• If you are deploying multiple Exalogic machines that will be connected to
form a single system, then contact your Oracle representative for
instructions.
• By default, there is one default InfiniBand partition at the Exalogic
machine level. All compute nodes in the Exalogic machine are members
of the default InfiniBand partition. The most common model for
application isolation involves multiple IP subnetting, in which the most
mission-critical applications are assigned their own IP subnets layered
above the default IPoIB link. In this model, some subnets may also
contain applications that have less stringent or otherwise different
resource requirements.
Yes No N/A Comment
Network Specification Checklist
Site Checklists B-9
