E.2 InfiniBand Network Cabling Tables

This section contains the tables for the InfiniBand network cabling. The Sun Network
QDR InfiniBand Gateway Switch is located in located in rack units 26, 24, 23, or 16
(depending on the rack configuration).
This section contains the following topics:
•

Exalogic Machine Full Rack

• Exalogic Machine Half Rack
• Exalogic Machine Quarter Rack
• Exalogic Machine Eighth Rack
E.2.1 Exalogic Machine Full Rack
This section contains the following tables:
• Table E-5
• Table E-6
• Table E-7
Table E-5
Exalogic machine full rack.
Table E-5
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
U26
U26
U26
U26
U26
U26
lists the location, ports and cables for the InfiniBand connections for an

InfiniBand Network Cabling for Exalogic Machine Full Rack

Port To Rack
Unit
9A U42
9B U41
10A U40
10B U39
11A U38
11B U37
InfiniBand Network Cabling Tables
Type of Port
Equipment
Compute node PCIe 2, P1
Compute node PCIe 2, P1
Compute node PCIe 2, P1
Compute node PCIe 2, P1
Compute node PCIe 2, P1
Compute node PCIe 2, P1
Description
3 meter QDR
InfiniBand cable
3 meter QDR
InfiniBand cable
3 meter QDR
InfiniBand cable
3 meter QDR
InfiniBand cable
3 meter QDR
InfiniBand cable
2 meter QDR
InfiniBand cable
Cabling Tables E-7
