Connect to ILOM via the Network
This section discusses the following topics:
•

Connect to the CLI

•

Connect to the Web GUI

•

Launch a Remote KVM Session

7.5.1 Connect to the CLI
Start your SSH client, such as PuTTY.
1.
In the Host Name (or IP address) field, enter the ILOM IP address of the Exalogic
2.
compute node or hardware component you want to connect to.
Ensure that SSH is chosen as the Connection Type.
3.
Type the user name and the password, when prompted. The default user name is
4.
root.
The CLI command prompt is displayed.
7.5.2 Connect to the Web GUI
In the address bar of a web browser, type the ILOM IP address of an Exalogic
1.
compute node or hardware component, and press Enter.
The login screen is displayed.
Enter the user name and the password. The default user name is root.
2.
Click Log In.
3.
The web GUI is displayed.
7.5.3 Launch a Remote KVM Session
To access the ILOM consoles for Exalogic machine components that are connected to
ILOM, do the following:
Ensure that pop-up blockers are disabled in your browser before you launch the
1.
remote console.
Type the ILOM IP address, which you noted down in the procedure
2.
Addresses for Exalogic Machine
Log in to ILOM using the default user name root. After login, the ILOM home
3.
page is displayed.
7-4 Oracle Exalogic Elastic Cloud Machine Owner's Guide
Note:
You can use this connection method only if ILOM IP addresses are configured
and can be accessed over the network. The network must be connected to the
NET0 port (with sideband) of each of the Exalogic compute nodes or hardware
components.
Oracle recommends that you use this connection method to access ILOM for
Exalogic compute nodes.
Components, in the address bar of a web browser.
ILOM IP
