Install a DIMM

All of the replacement DIMMs must be the same size and type. See
Configuration" on page
If you are upgrading the server, continue to remove all of the DIMM filler
■
panels from the new processor modules.
DIMM filler panels are not supported in running processor modules. After you have
removed all of the DIMM filler panels, you can install the new DIMMs. See
DIMM" on page
Related Information
"DIMM Configuration" on page 71
■
"Determine Which DIMM Is Faulty (FMA)" on page 73
■
"Determine Which DIMM Is Faulty (LEDs)" on page 75
■
"Install a DIMM" on page 78
■
"Server Upgrade Process" on page 59
■
Install a DIMM
Before beginning this procedure, ensure that you are familiar with the information provided in
these topics:
"Safety Information" on page 49
■
"DIMM Configuration" on page 71
■
Take the necessary ESD precautions.
1.
See "Prevent ESD Damage" on page
2. Ensure that you have removed the processor module if you are replacing a faulty
DIMM.
See "Remove a Processor Module or Processor Filler Module" on page
3. Ensure that you have removed the faulty DIMM.
See "Remove a DIMM or DIMM Filler Panel" on page
Unpack the replacement DIMM, and place it on an antistatic mat.
4.
Caution -
populated configuration to a fully-populated configuration, you must install the same size and
capacity of DIMMs that are already in the existing processor modules.
78 SPARC T5-8 Server Service Manual • November 2015
71.
78.
If you ordered processor modules without memory to upgrade the server from a half-
57.
76.
"DIMM
"Install a
63.
