5. Ensure that the ejector tabs on the connector that will receive the DIMM are in
the open position.
Align the DIMM notch with the key in the connector.
6.
Ensure that the orientation is correct. The DIMM might be damaged if the orientation
Caution -
is reversed.
Push the DIMM into the connector until the ejector tabs lock the DIMM in place.
7.
If the DIMM does not easily seat into the connector, check the DIMM's orientation.
8. Determine your next step.
If you replaced a faulty DIMM, go to Step 9.
■
If you are upgrading the server, repeat Step 5 through Step 7 until all of the new DIMMs are
■
installed. Then, go to
9. Install the PM.
See "Install a Processor Module or Processor Filler Module" on page
Related Information
"DIMM Configuration" on page 71
■
"Remove a DIMM or DIMM Filler Panel" on page 76
■
"Verify the DIMM" on page 80
■
"Server Upgrade Process" on page 59
■
"Server Upgrade Process" on page
Install a DIMM
59.
67.
Servicing DIMMs 79
