DIMM Configuration

DIMM Guidelines

You must follow these guidelines:
Use either 16- or 32-Gbyte DDR3 DIMM capacity DIMMs.
■
Use Oracle qualified DIMMs.
■
Fully-populate (32 DIMMs) all processor modules.
■
Caution -
populated configuration to a fully-populated configuration, you must install the same type and
size of DIMMs that are already in the existing processor modules.
If you are reviewing this information because you are upgrading the server, return to
Upgrade Process" on page

DIMM Locations

DIMM addresses, and consequently their NAC names, are based on their location on the
processor module motherboard, as well as the slot in which the processor is installed. For
example, the full address for the DIMM that is installed in the front-left corner of the processor
module that is installed in slot 0 is:
/System/Memory/DIMMs/DIMM_0.
or
/SYS/PM0/CM1/CMP/BOB0/CH0/D0.
This illustration shows the DIMM layout.
72 SPARC T5-8 Server Service Manual • November 2015
If you ordered processor modules without memory to upgrade the server from a half-
59.
"Server
