Remove a PCIe Card

This procedure involves handling circuit boards that are extremely sensitive to static
Caution -
electricity. Ensure that you follow ESD preventative practices to avoid damaging the circuit
boards. See "Prevent ESD Damage" on page
Ensure that you have already taken antistatic measures.
1.
See "Prevent ESD Damage" on page
2. Determine your next step:
a. If a carrier extension is installed, go to
Extension" on page
To provide adequate access to the card, you must remove the carrier extension if one is
installed.
If no carrier extension is installed, go to
b.
57.
57.
"Remove a Carrier
162.
Step
Remove a PCIe Card
3.
Servicing PCIe Cards 159
