Related Information
"Install a PCIe Card" on page 165
■
"Install a Card Carrier" on page 168
■

Install a PCIe Card

This procedure involves handling circuit boards that are extremely sensitive to static
Caution -
electricity. Ensure that you follow ESD preventative practices to avoid damaging the circuit
boards. See "Prevent ESD Damage" on page
Determine your first step:
1.
a. If you are installing a new card and need an empty carrier, see
Card Carrier" on page
b. If you are replacing a faulty card and have already removed its carrier from
the server, go to
Unlatch and swing open the top of the PCIe card carrier.
2.
Remove the PCIe card from its packaging.
3.
57.
155.
Step 3.
Install a PCIe Card
"Remove a
Servicing PCIe Cards 165
