If you are upgrading the server, return to
Note -
Related Information
"Root Complex Connections (Two Processor Modules)" on page 151
■
"PCIe Card Installation Guidelines" on page 153
■
"Server Upgrade Process" on page 59
■
Root Complex Connections (Two Processor
Modules)
This diagram illustrates the root complex connections between the two processor modules and
the 16 PCIe I/O slots in a half-populated server. Each CPU supports two I/O root complex
fabrics. Each root complex connects to four I/O slots through two of five multiplexing switches.
Switch
I/O Slot
1
3
2
9
3
11
0
2
1
4
2
10
3
12
1
5
2
7
3
13
4
15
1
6
2
8
3
14
4
16
"Server Upgrade Process" on page
Understanding PCIe Root Complex Connections
Root Complex Path
/pci@340/pci@1/pci@0/pci@6
/pci@380/pci@1/pci@0/pci@a
/pci@3c0/pci@1/pci@0/pci@e
/pci@400/pci@1/pci@0/pci@c
/pci@440/pci@1/pci@0/pci@c
/pci@480/pci@1/pci@0/pci@4
/pci@4c0/pci@1/pci@0/pci@8
/pci@500/pci@1/pci@0/pci@e
/pci@540/pci@1/pci@0/pci@e
/pci@580/pci@1/pci@0/pci@a
/pci@5c0/pci@1/pci@0/pci@8
/pci@600/pci@1/pci@0/pci@8
/pci@640/pci@1/pci@0/pci@8
/pci@680/pci@1/pci@0/pci@4
/pci@6c0/pci@1/pci@0/pci@4
Servicing PCIe Cards
59.
151
