Front Panel Components (Service) - Oracle SPARC T5-8 Service Manual

Front Panel Components (Service)

Front Panel Components (Service)
No.
1
2
3
4
Related Information
"Rear Panel Components (Service)" on page 15
■
14 SPARC T5-8 Server Service Manual • November 2015
Description
Hard drives (8)
Processor modules (0 to 3, bottom to top) or
processor filler modules (slot 1 and slot 2)
Main module
Power supplies (0 to 3, left to right)
Links
"Servicing Hard Drives"
"Supported Storage Devices" on page 18
"Servicing Processor Modules"
"Server Upgrade Process" on page 59
"Servicing the Main Module"
"Servicing Power Supplies"
