Menu 7: Analog I/O

Hardware
The drive has three analog inputs (AI1 to AI3) and two analog outputs (AO1 and AO2). Each input has a similar parameter structure and each output
has a similar parameter structure. The nominal full scale level for inputs in voltage mode is 9.8V. This ensures that when the input is driven from a
voltage produced from the drive's own 10V supply, the input can reach full scale.
Terminal Input
5/6 AI1
7 AI2
8 AI3
Terminal Output
9 AO1
10 AO2
Update rate
The analog inputs are sampled every 4ms except where the destinations shown in the table below are chosen, the input is in voltage mode and other
conditions necessary for short cutting are met.
Input destination
Pr 1.36 - Analog reference
Pr 1.37 - Analog reference
Pr 3.14 - Power ff comp
Pr 3.19 - Hard speed ref
Pr 4.08 - Torque reference
It should be noted that the analog inputs are always sampled every 4ms in Open-loop mode. However, the window filter applied to analog input 1 (see
Pr 7.26) can be set to a time that is shorter than 4ms. There is no advantage in doing this, as it simply reduces the resolution of the input data, which
is still only sampled and routed to its destination parameter every 4ms.
Analog outputs are updated every 4ms except when one of the following is the source and high speed update mode is selected. In high speed mode
the output operates in voltage mode, is updated every 250µs, special scaling is used as described in the table and the user scaling is ignored.
Output source
Pr 3.02 – speed
Pr 4.02 - torque prod current
Pr 4.17 - magnetising current
Pr 5.03 - output power
Unidrive SP Advanced User Guide
Issue Number: 7
Parameter Advanced parameter
description format descriptions
Input modes
Voltage only
(16 bit plus sign as a speed reference)
0 to 6
0 to 9
Output modes Resolution
0 to 3 10 bit plus sign
0 to 3 10 bit plus sign
Closed-loop vector or Servo mode sample rate
250µs
(AI1 subject to window filter. See Pr 7.26 on page 142)
250µs
(AI1 subject to window filter. See Pr 7.26 on page 142)
250µs
(AI1 subject to window filter. See Pr 7.26 on page 142)
AI1 – 4ms
AI2 or 3 – 250µs
(Closed-loop vector and servo modes only)
10.0V = SPEED_MAX
10.0V = Rated drive current / 0.45
10.0V = Rated drive current / 0.45
(Closed-loop vector and servo modes only)
The output is the product of the active current and the voltage component in phase
with the active current (vsy x isy).
10V would be produced when:
Active current = Rated drive current / 0.45
Peak phase voltage in phase with the active current = DC_VOLTAGE_MAX / 2
www.controltechniques.com
http://nicontrols.com
Serial comms
Macros
protocol
Resolution
12 bit plus sign
10 bit plus sign
10 bit plus sign
Regen mode sample rate
AI1 - 4ms
AI2 or 3 - 1ms
Scaling
Electronic Feature look-
Performance
nameplate up table
Menu 7
