Table 6-7 Parameter set-up to reproduce Macro 3 on a Unidrive SP
Parameter
8.21 T24 digital I/O 1 source / destination
8.25 T28 digital input 5 destination
8.26 T29 digital input 6 destination
8.31 T24 digital I/O 1 output select
8.39 T28 & T29 digital input auto selection disable
11.01 Define Pr 0.11
11.02 Define Pr 0.12
11.03 Define Pr 0.13
11.04 Define Pr 0.14
11.05 Define Pr 0.15
11.06 Define Pr 0.16
11.07 Define Pr 0.17
11.08 Define Pr 0.18
11.09 Define Pr 0.19
11.10 Define Pr 0.20
11.11 Define Pr 0.21
11.12 Define Pr 0.22
11.13 Define Pr 0.23
11.14 Define Pr 0.24
11.15 Define Pr 0.25
11.16 Define Pr 0.26
11.17 Define Pr 0.27
11.18 Define Pr 0.28
11.19 Define Pr 0.29
11.20 Define Pr 0.30
Unidrive SP Advanced User Guide
Issue Number: 7
Parameter Advanced parameter
x.00 description format descriptions
www.controltechniques.com
http://nicontrols.com
Serial comms
Macros
protocol
Value
OL CL
Pr 1.46
Pr 1.45
Pr 1.42
OFF (0)
On (1)
Pr 1.03
Pr 2.01
Pr 4.02
Pr 1.05
Pr 2.04
Pr 6.01
Pr 8.17
Pr 2.06
Pr 2.07
Pr 1.29
Pr 1.30
Pr 1.31
Pr 1.32
Pr 0.00
Pr 1.21
Pr 1.22
Pr 1.23
Pr 1.24
Pr 0.00
Pr 0.00
