Voltage controller gain

Drive modes Open-loop, Closed-loop vector, Servo
Bit SP FI
Coding
Range Open-loop, Closed-loop vector, Servo
Default Open-loop, Closed-loop vector, Servo
Update rate Background read
This parameter controls the gain of the voltage controller used for mains loss and standard ramp control. If the parameter is set to 1 the gain used is
suitable for applications where the drive is used alone. Higher values are intended for applications where the DC bus of each drive is connected in
parallel and the drive is used as a master for mains loss control. This is intended for use in applications where each drive is locked together using
open-loop frequency slaving. (If motors are locked together using digital-locking, using a master for mains loss control, it is unlikely that the system
will be stable during mains loss unless the power rating of the master is much higher than the combined rating of the slaves. This is due to the lag
created by the master motor inertia.)
5.32

Motor torque per amp (Kt)

Drive modes Closed-loop vector, Servo
Coding Bit SP
CLV
SV
Range Closed-loop vector, Servo
Default Servo
Update rate Background (1s) read
This parameter shows the motor torque per amp of active (torque producing) current used to calculate the speed controller gains when the automatic
set-up methods are active (i.e. Pr 3.17 = 1 or 2).
Closed-loop vector
The drive calculates the motor torque per amp of active current using the motor parameters as shown below assuming a motor efficiency of 90%.
√3 x Vrated x Irated x Rated power factor x Efficiency
Kt =
-1
Rated speed (rad s
√3 x Pr 5.09 x Pr 5.07 x Pr 5.10 x 0.9
Kt =
(2π x Pr 5.08 / 60) x Rated active current
Rated active current is the active current when the motor current is equal to the rated motor current and is defined at the start of the description of
menu 4.
Servo
The motor torque per amp (Kt) must be entered in this parameter by the user for the automatic gain calculation system to operate correctly.
5.33

Motor volts per 1000rpm (Ke)

Drive modes Servo
Bit SP FI
Coding
Range Servo
Default Servo
Second motor
Servo
parameter
Update rate Background read
This parameter is used to set up the current controller integral terms when the drive is disabled to prevent current transients when the drive is enabled
with a spinning motor. It is also used to provide a voltage feed forward term if high dynamic performance is selected with Pr 5.26.
