157 Y File Corruption Error - Consult Factory
158 Y File Corruption Error - Consult Factory
159 Y File Corruption Error - Consult Factory
160 Y File Corruption Error - Consult Factory
161 Y File Corruption Error - Consult Factory
162 Y File Corruption Error - Consult Factory
163 Y File Corruption Error - Consult Factory
164 Y File Corruption Error - Consult Factory
165 Y File Corruption Error - Consult Factory
Program Error - EZMotion Parameter
166 Y
Write Out of Range
171 Y Invalid Slot 1 Selection
172 Y Invalid Slot 2 Selection
173 Y Invalid Slot 3 Selection
174 Y File Corruption Error - Consult Factory
175 Y Module Output Overload
Unidrive SP Advanced User Guide
Issue Number: 7
Parameter Advanced parameter
description format descriptions
Error
Value written to SM-EZMotion
parameter in user program is out of
range
Option module selected for Slot 1 in
PowerTools Pro file does not match
actual module type fitted
Option module selected for Slot 2 in
PowerTools Pro file does not match
actual module type fitted
Option module selected for Slot 3 in
PowerTools Pro file does not match
actual module type fitted
SM-EZMotoin module can only supply
20mA maximum total output current. If
this fault occurs, the digital output
device attached to the module outputs
is drawing too much current.
