T9 Analog Output 1 Source; T9 Analog Output 1 Scaling; T9 Analog Output 1 Mode; T10 Analog Output 2 Source - Control Techniques unidrive sp Advanced User's Manual

Parameter Keypad and Parameter
structure display x.00
7.19

T9 analog output 1 source

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop
Default Closed-loop vector, Servo
Regen
Update rate Background read
7.20

T9 analog output 1 scaling

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
7.21

T9 analog output 1 mode

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
The following modes are available for the analog outputs.
Parameter value Parameter string
0
1
2
3 H.Spd
If high speed update mode is selected and the source for the output is one of the parameters designated for high speed analog output operation (see
start of this section) the output is updated at a higher rate with special scaling. If the parameter selected is not designated for this mode the output is
updated at the normal rate. If speed feedback or power is selected for high speed mode for both analog output 1 and analog output 2 the setting is
ignored for analog output 2. If the high speed mode is selected the output is always a voltage signal.
7.22

T10 analog output 2 source

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo
Default
Regen
Update rate Read on drive reset
Unidrive SP Advanced User Guide
Issue Number: 7
Parameter Advanced parameter
description format descriptions
DE Txt VM DP ND
2
Pr 0.00 to Pr 21.51
Pr 5.01
Pr 3.02
Pr 4.01
DE Txt VM DP ND
3
0.000 to 4.000
1.000
DE Txt VM DP ND
1
0 to 3
0
Mode
VOLt Voltage mode
0-20 0 - 20mA
4-20 4 - 20mA
High speed up date mode
DE Txt VM DP ND
2
Pr 0.00 to Pr 21.51
Pr 4.02
Pr 5.05
www.controltechniques.com
http://nicontrols.com
Serial comms
Macros
protocol
RA NC NV PT US RW BU
1 1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1 1
Electronic Feature look-
Performance
nameplate up table
PS
1
PS
1
PS
1
PS
1
Menu 7
141
