Table 6-11 Parameter set-up to reproduce Macro 5 on a Unidrive SP
Parameter
7.10 Analog input 1 destination
7.14 Analog input 2 destination
7.18 Analog input 3 destination
8.26 T29 digital input 6 destination
8.39 T28 and T29 digital input auto selection disable
11.01 Define Pr 0.11
11.02 Define Pr 0.12
11.03 Define Pr 0.13
11.04 Define Pr 0.14
11.05 Define Pr 0.15
11.06 Define Pr 0.16
11.07 Define Pr 0.17
11.08 Define Pr 0.18
11.09 Define Pr 0.19
11.10 Define Pr 0.20
11.11 Define Pr 0.21
11.12 Define Pr 0.22
11.13 Define Pr 0.23
11.14 Define Pr 0.24
11.15 Define Pr 0.25
11.16 Define Pr 0.26
11.17 Define Pr 0.27
11.18 Define Pr 0.28
11.19 Define Pr 0.29
11.20 Define Pr 0.30
14.02 Main reference source
14.03 PID reference source
14.04 PID feedback source
14.16 PID output destination
Unidrive SP Advanced User Guide
Issue Number: 7
Parameter Advanced parameter
x.00 description format descriptions
www.controltechniques.com
http://nicontrols.com
Serial comms
Macros
protocol
Value
OL CL
Pr 0.00
Pr 1.27
Pr 1.28
Pr 14.08
On (1)
Pr 1.03
Pr 2.01
Pr 4.02
Pr 0.00
Pr 7.11
Pr 7.15
Pr 7.01
Pr 7.02
Pr 7.03
Pr 14.10
Pr 14.11
Pr 14.12
Pr 14.13
Pr 14.14
Pr 14.15
Pr 1.27
Pr 1.28
Pr 7.12
Pr 7.16
Pr 14.09
Pr 7.01
Pr 1.27
Pr 1.28
Pr 1.36
