Parameter
Keypad and
Menu 12
structure
display
12.43
Low current threshold
Drive modes
Open-loop, Closed-loop vector, Servo
Coding
Bit
SP
Range
Open-loop, Closed-loop vector, Servo
Default
Open-loop, Closed-loop vector, Servo
Update rate
Background read
If the current magnitude falls below the lower current threshold the brake is applied immediately. The lower threshold should be set to the required
level to detect the condition where the motor has been disconnected from the drive.
Brake apply speed
12.45
Drive modes
Closed-loop vector, Servo
Coding
Bit
SP
Range
Closed-loop vector, Servo
Default
Closed-loop vector, Servo
Update rate
Background read
When stopping, the drive reference can be removed (i.e. Pr 1.11 = 0), but the brake will remain energised (open) until the motor has remained at a
speed below the brake apply speed for the delay defined by Pr 12.46. The delay prevents rapid activation and de-activation of the brake when fine
control of a motor is required close to zero speed.
12.46
Brake apply speed delay
Drive modes
Closed-loop vector, Servo
Coding
Bit
SP
Range
Closed-loop vector, Servo
Default
Closed-loop vector, Servo
Update rate
Background read
See Pr 12.45.
Post-brake release delay
12.47
Drive modes
Closed-loop vector, Servo
Coding
Bit
SP
Range
Closed-loop vector, Servo
Default
Closed-loop vector, Servo
Update rate
Background read
The post-brake release time is used to allow for the brake release time. From the time that the drive is enabled and then during this period the speed
reference is held constant at zero, so that there is no sudden increase in motor speed when the brake actually releases.
Brake-apply delay
12.48
Drive modes
Closed-loop vector, Servo
Coding
Bit
SP
Range
Closed-loop vector, Servo
Default
Closed-loop vector, Servo
Update rate
Background read
The brake apply delay is used to allow for the brake application time. During this period the Hold zero speed parameter (Pr 6.08) is one, and so the
drive is enabled with zero speed reference. This ensures that the motor remains stationary while the brake is being applied.
204
Parameter
Parameter
x.00
description format
FI
DE
Txt VM DP
ND
0 to 200 %
10
FI
DE
Txt VM DP
ND
0 to 200 rpm
5
FI
DE
Txt VM DP
ND
1
0.0 to 25.0 s
1.0
FI
DE
Txt VM DP
ND
1
0.0 to 25.0 s
1.0
FI
DE
Txt VM DP
ND
1
0.0 to 25.0 s
1.0
www.controltechniques.com
http://nicontrols.com
Advanced parameter
Macros
descriptions
RA
NC
NV
PT
US RW BU
1
1
RA
NC
NV
PT
US RW BU
1
1
RA
NC
NV
PT
US RW BU
1
1
RA
NC
NV
PT
US RW BU
1
1
RA
NC
NV
PT
US RW BU
1
1
Serial comms
Electronic
Performance
protocol
nameplate
PS
1
PS
1
PS
1
PS
1
PS
Unidrive SP Advanced User Guide
Issue Number: 7
