Orientation position complete

Drive modes Closed-loop vector, Servo
Bit SP
Coding
1
Update rate 4ms write
Pr 13.13 defines the position as a 1/2
16
reference for orientation in 1/2
complete.
13.16

Position error reset

Drive modes Open-loop, Closed-loop vector, Servo
Bit SP
Coding
1
Default Open-loop, Closed-loop vector, Servo
Update rate 4ms read
The position error integrator is preset to the absolute error (Pr 13.10 is 1 or 2, and Pr 13.11 is one) otherwise it is set to zero when this parameter is
set to one.
The position controller is disabled and the error integrator is also reset under the following conditions:
1. If the drive is disabled (i.e. inhibited, ready or tripped)
2. If the position controller mode (Pr 13.10) is changed. The position controller is disabled transiently to reset the error integrator.
3. The absolute mode (Pr 13.11) is changed. The position controller is disabled transiently to reset the error integrator.
4. One of the position sources is invalid.
5. The position feedback initialised (Pr 3.48) is zero.
13.17

Relative jog reference

Drive modes Open-loop, Closed-loop vector, Servo
Bit SP
Coding
Range Open-loop, Closed-loop vector, Servo
Default Open-loop, Closed-loop vector, Servo
Update rate Background read
13.18

Relative jog enable

Drive modes Open-loop, Closed-loop vector, Servo
Bit SP
Coding
1
Default Open-loop, Closed-loop vector, Servo
Update rate 4ms read
13.19 Relative jog reverse
Drive modes Open-loop, Closed-loop vector, Servo
Bit SP
Coding
1
Default Open-loop, Closed-loop vector, Servo
Update rate Background read
Relative jog can be used to move the feedback position relative to the reference position at a speed defined by Pr 13.17.
