Control Techniques unidrive sp Advanced User's Manual page 285

Menus 15 to 17 Parameter Keypad and
Fieldbus structure display
x.33 Download from Fieldbus Solutions Module
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
1
Default All drive types
Pr x.33 is used to configure the Solutions Module set-up menu with values stored within the Fieldbus Solutions Modules flash memory and is cleared
once 'download' performed.
The parameter will be continuously polled. When set, the following will occur:
1. Fieldbus communication will be stopped.
2. Fieldbus menu parameter values will be downloaded to the Unidrive SP from the Solutions Modules flash memory - if a valid parameter set has
not been saved then a trip 70 will occur.
3. Pr x.33 will be cleared.
4. The module will reset itself.
5. The Solutions Module will perform its standard start-up procedure using the downloaded values.
x.34 Compression
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
1
Default All drive types
Range All drives
If this parameter is set to 'OFF' then all mapped parameters (except PPONC which is 64 bit) will be treated as 32 bit. This provides the user with a
simpler method of configuring the cyclic data. The negative aspect is that network bandwidth can be wasted. If the parameter is set to 'ON' then all
mapped parameters that are 16 bits or less, will only require 16bits of data to be transmitted.
x.35 Serial Number
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Default All drives
Range All drives
The serial number is programmed into the product during manufacture. This enables the hardware and software compatibility to be checked, and
provide each module with a unique identifier that is accessible via software.
x.36 Fieldbus specific
x.37 Fieldbus specific
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
1
Default All drive types
x.38 Fieldbus specific defined mode
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Default All drives
Range All drives
Used to enable cyclic data configurations that have been pre-defined in the fieldbus specifications. See fieldbus specific documentation for more
details.
284
Parameter Parameter
x.00 description format
FI DE Txt VM DP ND
0
FI DE Txt VM DP ND
0
0 to 1
FI DE Txt VM DP ND
1
0
-2,147,483,648 to 2,147,483,647
FI DE Txt VM DP ND
0
FI DE Txt VM DP ND
0
0 to 255
www.controltechniques.com
http://nicontrols.com
Advanced parameter
Macros
descriptions
RA NC NV PT US RW BU
1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
Serial comms Electronic
Performance
protocol nameplate
PS
PS
PS
PS
PS
1
Unidrive SP Advanced User Guide
Issue Number: 7
Feature look-
up table
