Parameter Keypad and
Menu 6
structure display
6.23

Run time: hours.minutes

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Update rate Background write
The run time clock increments when the drive inverter is active to indicate the number of minutes that the drive has been running since leaving the
Control Techniques factory. This clock may be used for time stamping the trip log if Pr 6.28 = 1.
6.24

Energy meter: MWh

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Update rate Background write
6.25

Energy meter: kWh

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Update rate Background write
Pr 6.24 and Pr 6.25 form the energy meter that indicates energy supplied to/from the drive in kWh. For motor control modes a positive value indicates
net transfer of energy from the drive to the motor. For Regen mode a positive value indicates a net transfer of energy from the supply to the drive. The
energy meter is reset and held at zero when Pr 6.17 is one.
6.26

Running cost

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Update rate Background write
Instantaneous read out of the cost/hour of running the drive. This requires Pr 6.16 to be set up correctly.
6.27 Time before filter change due
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Update rate Background read
See Pr 6.18 on page 127.
128
Parameter Parameter
x.00 description format
DE TE VM DP ND
2 1
0 to 23.59 Hours.Minutes
DE TE VM DP ND
1 1
±999.9 MWh
DE TE VM DP ND
2 1
±99.99 kWh
DE TE VM DP ND
1 1
±32,000
DE TE VM DP ND
1
0 to 30,000 hrs
www.controltechniques.com
http://nicontrols.com
Advanced parameter
Macros
descriptions
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
Serial comms Electronic
Performance
protocol nameplate
PS
1 1
PS
1
PS
1
PS
PS
1 1
Unidrive SP Advanced User Guide
Issue Number: 7
Feature look-
up table
