Parameter Keypad and Parameter
structure display x.00
Table 5-9
I/O state
Terminal and Type
Parameter
T2 input / output 1 Pr x.09
T3 input / output 2 Pr x.10
T4 input / output 3 Pr x.03
T6 input 4 Pr x.04
T7 Input 5 Pr x.05
T8 Input 6 Pr x.06
T21 Relay 7 Pr x.07
T23 Relay 8 Pr x.08
Figure 5-31 SM-I/O Plus Analog Input/Output logic diagram
The module has two analog inputs (AI1 and AI2) and one analog output (AO1). The inputs operate in voltage mode only and the nominal full scale
level in voltage mode is 9.8V. This ensures that when the input is driven from a voltage produced from the drive's own 10V supply, the input can reach
full scale. The output operates in voltage mode only.
Unidrive SP Advanced User Guide
Issue Number: 7
Parameter Advanced parameter
description format descriptions
Invert
Parameter Default
Pr x.11 0
Pr x.12 0
Pr x.13 0
Pr x.14 0
Pr x.15 0
Pr x.16 0
Pr x.17 0
Pr x.18 0
T9 Analog input 4
X.40
T9 Analog input 4
T10 Analog input 5
X.44
T10 Analog input 5
T10 Analog
www.controltechniques.com
http://nicontrols.com
Serial comms
Macros
protocol
Source/
destination
Parameter Default
Pr x.21 00.00
Pr x.22 00.00
Pr x.23 00.00
Pr x.24 00.00
Pr x.25 00.00
Pr x.26 00.00
Pr x.27 00.00
Pr x.28 00.00
X.41
T9 Analog
input 4 x(-1)
scaling
X.42
T9 Analog input
4 invert
T10 Analog
X.45
input 5
x(-1)
scaling
X.46
T10 Analog input
5 invert
Key
Input
0.XX
terminals
Output
0.XX
terminals
The parameters are all shown at their default settings
Electronic Feature look-
Performance
nameplate up table
Output select
Parameter Default
Pr x.31 0
Pr x.32 0
Pr x.33 0
T9 Analog
input 4
destination Any
unprotected
X.43
variable
parameter
??.??
??.??
input 5
destination Any
unprotected
X.47
variable
parameter
??.??
??.??
Read-write (RW)
parameter
Read-only (RO)
parameter
Menus 15 to 17
SM-I/O Plus
