3.7

Menu 7: Analog inputs and outputs

Parameter
7.01 Analog input 1 (Terminal 2)
7.02 Analog input 2 (Terminal 5)
7.03 Not used
7.04 Heatsink temperature
7.05~
Not used
7.07
7.08 Analog input 1 scaling
7.09 Analog input 1 invert bit
7.10 Analog input 1 destination parameter
7.11 Analog input 2 mode selector
7.12 Analog input 2 scaling
7.13 Analog input 2 invert bit
7.14 Analog input 2 destination parameter
7.15~
Not used
7.18
Analog output source selector
7.19
(Terminal 6)
7.20 Analog output scaling
7.21~
Not used
7.27
7.28 Current loop loss indicator
7.29~
Not used
7.32
7.33 Analog output select
Commander SE Advanced User Guide
Issue Number: 4
Range Type
0 ~ 100.0% RO Uni
0 ~ 100.0% RO Uni
0 ~ 100°C RO Uni
0.00 ~ 2.50 RW Uni
0 or 1 RW Bit
0.00 ~ 21.51
RW Uni
Menu.parameter
(0)0 ~ 20
(1)20 ~ 0
(2)4 ~ 20
RW Uni
(3)20 ~ 4
(4)4 ~ .20
(5)20 ~ .4
0.00 ~ 2.50 RW Uni
0 or 1 RW Bit
0.00 ~ 21.51
RW Uni
Menu.parameter
0.00 ~ 21.51
RW Uni
Menu.parameter
0.00 ~ 2.50 RW Uni
0 or 1 RO Bit
(0)Fr
(1)Ld RW Uni
(2)Adv
Default
P
P
P
1.0
0
R P P1.36
Txt (4)4-.20
1.0
0
R P P1.37
2.01-Post ramp
P
reference
1.0
P
Txt R (0)Fr
Update
Setting
Rate
L2
L2
B
B, I
L2
I
L2
B, I
L2
I
B, I
L3
L2
B
