9.10 Logic function 1 destination
9.20 Logic function 2 destination
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Read on reset
9.21 Motorised pot mode
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
The motorised pot modes are given in the following table.
Pr 9.21 Mode
0 Zero at power-up
1 Last value at power-up
Zero at power-up and only change
2
when drive running
Last value at power-up and only
3
change when drive running
9.22 Motorised pot bipolar select
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
1
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate 4ms x number of menu 9 or 12 functions active read
When this bit is set to 0 the motorised pot output is limited to positive values only (i.e. 0 to 100.0%). Setting it to 1 allows negative outputs (i.e. ±100.0
%).
9.23 Motorised pot rate
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
This parameter defines the time taken for the motorised pot function to ramp from 0 to 100.0%. Twice this time will be taken to adjust the output from
-100.0 % to +100.0 %.
