Control Techniques unidrive sp Advanced User's Manual page 173

Parameter Keypad and
Menu 10
structure display
Trip
SLX.Er Solutions Module slot X trip: Solutions Module in slot X has detected a fault
Fieldbus module category
Check value in Pr 15/16/17.50. The following table lists the possible error codes for the Fieldbus modules.
Error code
52
61
65
66
67
68
202,207,212
69
70
71
74
98
99
SLX.HF Solutions Module slot X trip: Solutions Module X hardware fault
Ensure Solutions Module is fitted correctly
200,205,210
Return Solutions Module to supplier
SLX.nF Solutions Module slot X trip: Solutions Module has been removed
Ensure Solutions Module is fitted correctly
203,208,213 Re-fit Solutions Module
Save parameters and reset drive
SL.rtd Solutions Module trip: Drive mode has changed and Solutions Module parameter routing is now incorrect
Press reset.
215
If the trip persists, contact the supplier of the drive.
SLX.tO Solutions Module slot X trip: Solutions Module watchdog timeout
Press reset.
203,208,211
If the trip persists, contact the supplier of the drive.
t010
User trip defined in 2
10 SM-Applications program must be interrogated to find the cause of this trip
t036 to t038
User trip defined in 2
36 to 38 SM-Applications program must be interrogated to find the cause of this trip
t040 to t089
User trip defined in 2
40 to 89 SM-Applications program must be interrogated to find the cause of this trip
t099
User trip defined in 2
99 SM-Applications program must be interrogated to find the cause of this trip
t111 to t160
User trip defined in 2
111 to 160 SM-Applications program must be interrogated to find the cause of this trip
t168 to t175
User trip defined in 2
168 to 175 SM-Applications program must be interrogated to find the cause of this trip
t177 to t178
User trip defined in 2
177 to 178 SM-Applications program must be interrogated to find the cause of this trip
t216 to t217
User trip defined in 2
216 to 217 SM-Applications program must be interrogated to find the cause of this trip
172
Parameter Parameter
x.00 description format
Fieldbus Option
All except DPLCAN Control word user trip
All Invalid configuration parameters.
All except DPLCAN Network loss
DeviceNet, CANopen and
"Bus-Off" Node sees an excessive number of transmission errors.
DPLCAN
CANopen Node has not received a SYNC telegram within a specified time - to be defined.
CANopen Node has not received the guarding telegram within the time period specified.
Node sends a data frame and no other node acknowledges
DPLCAN
receipt of the frame message.
No valid Fieldbus Menu data available in the module to download to the drive –
All The user may not have saved any data, or the data save may not have been
completed successfully.
The External power supply has been lost. This trip will only occur if the module
DeviceNet was on line with a master when the loss occurs. i.e. will not occur if the power
supply is not present during module initialisation.
All The Solutions Module has overheated.
All The Solutions Module background task has not been completed.
All Software Fault.
nd
processor Solutions Module code
nd
processor Solutions Module code
nd
processor Solutions Module code
nd
processor Solutions Module code
nd
processor Solutions Module code
nd
processor Solutions Module code
nd
processor Solutions Module code
nd
processor Solutions Module code
