Parameter Keypad and
Menu 7
structure display
7.23

T10 analog output 2 scaling

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
7.24

T10 analog output 2 mode

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
The following modes are available for the analog outputs.
Parameter value Parameter string
0
1
2
3 H.Spd
If high speed update mode is selected and the source for the output is one of the parameters designated for high speed analog output operation (see
start of this section) the output is updated at a higher rate with special scaling. If the parameter selected is not designated for this mode the output is
updated at the normal rate. If speed feedback or power is selected for high speed mode for both analog output 1 and analog output 2 the setting is
ignored for analog output 2. If the high speed mode is selected the output is always a voltage signal.
7.25

Calibrate T5/6 analog input 1 full scale

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
1
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
Setting this bit will cause the drive to re-calibrate the full scale level of analog input 1 provided the input voltage is below +1.5V or above +2.5V. This
parameter is cleared by the software automatically when the calibration is complete. If the input voltage is above +2.5V the input voltage itself is used
for calibration, and so after calibration this level will be full scale for the input. If the input voltage is below +1.5V the internal reference is used for
calibration, and so the full scale will be nominally 9.8V after calibration. The calibration level is automatically stored on power-down. It should be noted
that the Analog input 1 offset trim is included in the input voltage when the input voltage itself is used for calibration, but this trim is not included when
the internal reference is used for calibration.
7.26

T5/6 analog input 1 sample time

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
Analog input 1 is filtered using a window filter to remove quantisation noise and adjust the resolution of this input. The length of the window can be
adjusted with this parameter. The shortest possible window is 250µs. It should be noted that if this input is not used as a speed reference (Pr 1.36, Pr
142
Parameter Parameter
x.00 description format
DE Txt VM DP ND
3
0.000 to 4.000
1.000
DE Txt VM DP ND
1
0 to 3
0
Mode
VOLt Voltage mode
0-20 0 - 20mA
4-20 4 - 20mA
High speed up date mode
DE Txt VM DP ND RA
0
DE Txt VM DP ND
1
0 to 8.0 ms
4.0
www.controltechniques.com
http://nicontrols.com
Advanced parameter
Macros
descriptions
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
Serial comms Electronic
Performance
protocol nameplate
PS
1
PS
1
PS
PS
1
