Control Techniques unidrive sp Advanced User's Manual page 291

Menus 15 to 17 Parameter Keypad and
SM-Applicat'ns structure display
x.04 Available system resource
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Default All drives
Range All drives
Update Rate Every 200ms
Displays free CPU resource as current background execution time / 200ms x 100%
RS485 address ♣
x.05
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Default All drives
Range All drives
Update Rate Not Applicable
RS485 mode ♣
x.06
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Default All drives
Range All drives
Update Rate Not Applicable
RS485 baud rate ♣
x.07
Drive types Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Default All drives
Range All drives
Update Rate Not Applicable
These parameters are the general setup parameters for the RS485 port. The following baud rate strings are defined:
Display Value
300 0
600 1
1200 2
2400 3
4800 4
9600 5
19200 6
38400 7
57600 8
115200 9 115200 baud
290
Parameter Parameter
x.00 description format
FI DE Txt VM DP ND
0
0 to 100
FI DE Txt VM DP ND
11
0 to 255
FI DE Txt VM DP ND
1
0 to 255
FI DE Txt VM DP ND
1
4
0 to 9
Description
300 baud
600 baud
1200 baud
2400 baud
4800 baud
9600 baud
19200 baud
38400 baud
57600 baud
www.controltechniques.com
http://nicontrols.com
Advanced parameter
Macros
descriptions
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
Serial comms Electronic
Performance
protocol nameplate
PS
1
PS
1
PS
1
PS
1
Unidrive SP Advanced User Guide
Issue Number: 7
Feature look-
up table
