Access Level; User Security; Changing The Access Level; Setting User Security - Control Techniques unidrive sp Advanced User's Manual

Parameter Keypad and
Parameter x.00
structure display
2.7.1

Access Level

The access level is set in Pr 0.49 and allows or prevents access to the
advanced menu parameters.
L1 access selected - Menu 0 only visible
Pr 0.00 Pr 1.00 ............
Pr 0.01 Pr 1.01 ............
Pr 0.02 Pr 1.02 ............
Pr 0.03 Pr 1.03 ............
............
............
Pr 0.49 Pr 1.49 ............
Pr 0.50 Pr 1.50 ............
L2 access selected - All parameters visible
Pr 0.00 Pr 1.00 ............
Pr 0.01 Pr 1.01 ............
Pr 0.02 Pr 1.02 ............
Pr 0.03 Pr 1.03 ............
............
............
Pr 0.49 Pr 1.49 ............
Pr 0.50 Pr 1.50 ............
2.7.2

Changing the Access Level

The Access Level is determined by the setting of Pr 0.49 as follows:
String Value
L1 0 Access to menu 0 only
L2 1 Access to all menus (menu 0 to menu 21)
The Access Level can be changed through the keypad even if the User
Security has been set.
12
Parameter Advanced parameter
description format descriptions
Pr 19.00 Pr 20.00
Pr 19.01 Pr 20.01
Pr 19.02 Pr 20.02
Pr 19.03 Pr 20.03
Pr 19.49 Pr 20.49
Pr 19.50 Pr 20.50
Pr 20.00 Pr 21.00
Pr 20.01 Pr 21.01
Pr 20.02 Pr 21.02
Pr 20.03 Pr 21.03
Pr 20.49 Pr 21.49
Pr 20.50 Pr 21.50
Effect
www.controltechniques.com
http://nicontrols.com
Serial comms
Macros
protocol
2.7.3

User Security

The User Security, when set, prevents write access to any of the
parameters (other than Pr. 0.49 Access Level) in any menu.
User security open - All parameters: Read / Write access
Pr 0.00 Pr 1.00 ............
Pr 0.01 Pr 1.01 ............
Pr 0.02 Pr 1.02 ............
Pr 0.03 Pr 1.03 ............
............
............
Pr 0.49 Pr 1.49 ............
Pr 0.50 Pr 1.50 ............
User security closed - All parameters: Read Only access
Pr 0.00 Pr 1.00 ............
Pr 0.01 Pr 1.01 ............
Pr 0.02 Pr 1.02 ............
Pr 0.03 Pr 1.03 ............
............
............
Pr 0.49 Pr 1.49 ............
Pr 0.50 Pr 1.50 ............

Setting User Security

Enter a value between 1 and 999 in Pr 0.34 and press the
the security code has now been set to this value. In order to activate the
security, the Access level must be set to Loc in Pr 0.49. When the drive
is reset, the security code will have been activated and the drive returns
to Access Level L1. The value of Pr 0.34 will return to 0 in order to hide
the security code. At this point, the only parameter that can be changed
by the user is the Access Level Pr 0.49.
Unlocking User Security
Select a read write parameter to be edited and press the
upper display will now show CodE. Use the arrow buttons to set the
security code and press the
With the correct security code entered, the display will revert to the
parameter selected in edit mode.
If an incorrect security code is entered the display will revert to
parameter view mode.
To lock the User Security again, set Pr 0.49 to Loc and press the
reset button.
Disabling User Security.
Unlock the previously set security code as detailed above. Set Pr 0.34 to
0 and press the button. The User Security has now been disabled,
and will not have to be unlocked each time the drive is powered up to
allow read / write access to the parameters.
Electronic Feature look-
Performance
nameplate up table
Pr 20.00 Pr 21.00
Pr 20.01 Pr 21.01
Pr 20.02 Pr 21.02
Pr 20.03 Pr 21.03
Pr 20.49 Pr 21.49
Pr 20.50 Pr 21.50
Pr 20.00 Pr 21.00
Pr 20.01 Pr 21.01
Pr 20.02 Pr 21.02
Pr 20.03 Pr 21.03
Pr 20.49 Pr 21.49
Pr 20.50 Pr 21.50
button, the
button.
Unidrive SP Advanced User Guide
Issue Number: 7
button;
