Parameter Keypad and
Menu 6
structure display
Bits marked with * have no effect in Regen mode.
Bit Function
0 Drive enable
1* Run forward
2* Jog
3* Run reverse
4* Forward/reverse
5* Run
6* Not stop
7 Auto/manual
8* Analogue/Preset reference
9* Jog reverse
10 Reserved
11 Reserved
12 Trip drive
13 Reset drive
14 Keypad watchdog
Bits 0-7 and bit 9: sequencing control
When the control word is enabled (Pr 6.43 = 1), and the Auto/manual bit (bit7) are both one, bits 0 to 6 and bit 9 of the control word become active.
The equivalent parameters are not modified by these bits, but become inactive when the equivalent bits in the control word are active. When the bits
are active they replace the functions of the equivalent parameters. For example, if Pr 6.43 = 1 and bit 7 of Pr 6.42 = 1 the drive enable is no longer
controlled by Pr 6.15, but by bit 0 of the control word. If either Pr 6.43 = 0, or bit 7 of Pr 6.42 = 0, the drive enable is controlled by Pr 6.15.

Bit 8: Analog/preset reference

When the control word is enabled (Pr 6.43) bit 8 of the control word becomes active. (Bit 7 of the control word has no effect on this function.) The state
of bit 8 is written to Pr 1.42. With default drive settings this selects analogue reference 1 (bit8 = 0) or preset reference 1 (bit8 = 1). If any other drive
parameters are routed to Pr 1.42 the value of Pr 1.42 is undefined.

Bit12: Trip drive

When the control word is enabled (Pr 6.43) bit 12 of the control word becomes active. (Bit 7 of the control word has no effect on this function.) When
bit 12 is set to one a CL.bit trip is initiated. The trip cannot be cleared until the bit is set to zero

Bit 13: Reset drive

When the control word is enabled (Pr 6.43) bit 13 of the control word becomes active. (Bit 7 of the control word has no effect on this function.) When
bit 13 is changed from 0 to 1 the drive is reset. This bit does not modify the equivalent parameter (Pr 10.33).
Bit 14: Keypad watchdog
When the control word is enabled (Pr 6.43) bit 14 of the control word becomes active. (Bit 7 of the control word has no effect on this function.) A
watchdog is provided for an external keypad or other device where a break in the communication link must be detected. The watchdog system can be
enabled and/or serviced if bit 14 of the control word is changed from zero to one with the control word enabled. Once the watchdog is enabled it must
be serviced at least once every second or an "SCL" trip occurs. The watchdog is disabled when an "SCL" trip occurs, and so it must be re-enabled
when the trip is reset.
6.44

Active supply

Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP FI
Coding
1
Update rate Background write
The drive can operate from either a high voltage supply or a low voltage supply, usually from a battery. Different methods are used to connect the low
voltage battery supply depending on the frame size of the drive. This parameter, which indicates which supply is active, is set up to the correct value
just as the UU trip is reset. A low voltage battery supply should not be used without first consulting the appropriate documentation on the power and
control connections required for this mode.
0: Normal high voltage supply
The drive is operating in normal high voltage supply mode.
UNISP1xxx, UNISP2xxx, UNISP3xxx:
The drive is using the main power terminals to derive its control supplies. The drive will operate normally. Parameters that are saved at power-down
are saved when the supply is removed and a UU trip occurs.
UNISP4xxx, UNISP5xxx, UNISP6xxx, UNISP7xxx:
The drive is using the main power terminals to derive its control supplies and the battery mode enable power supply input has no supply connected.
The drive will operate normally. Parameters that are saved at power-down are saved when the supply is removed and a UU trip occurs.
1: Low voltage battery supply
The drive is operating in low voltage battery supply mode.
132
Parameter Parameter
x.00 description format
Equivalent parameter
Pr 6.15
Pr 6.30
Pr 6.31
Pr 6.32
Pr 6.33
Pr 6.34
Pr 6.39
Pr 1.42
Pr 6.37
Pr 10.33
DE TE VM DP ND RA
1
www.controltechniques.com
http://nicontrols.com
Advanced parameter
Macros
descriptions
NC NV PT US RW BU
1 1
Serial comms Electronic
Performance
protocol nameplate
PS
Unidrive SP Advanced User Guide
Issue Number: 7
Feature look-
up table
