Control Techniques unidrive sp Advanced User's Manual page 33

Parameter Keypad and
Menu 1
structure display
stored in memory preventing the possibility of data skew.
1.21 Preset reference 1
1.22 Preset reference 2
1.23 Preset reference 3
1.24 Preset reference 4
1.25 Preset reference 5
1.26 Preset reference 6
1.27 Preset reference 7
1.28 Preset reference 8
Drive modes Open-loop, Closed-loop vector, Servo
Bit SP
Coding
Range Open-loop, Closed-loop vector, Servo
Default Open-loop, Closed-loop vector, Servo
Update rate 4ms read
1.29 Skip reference 1
1.31 Skip reference 2
1.33 Skip reference 3
Drive modes Open-loop, Closed-loop vector, Servo
Bit SP
Coding
Closed-loop vector and servo DP = 0
Open-loop
Range
Closed-loop vector, Servo
Open-loop
Default
Closed-loop vector, Servo
Update rate Background read
See below.
1.30 Skip reference band 1
1.32 Skip reference band 2
1.34 Skip reference band 3
Drive modes Open-loop, Closed-loop vector, Servo
Bit SP
Coding
Closed-loop vector and servo DP = 0
Open-loop
Range
Closed-loop vector, Servo
Open-loop
Default
Closed-loop vector, Servo
Update rate Background read
Three skip references are available to prevent continuous operation at a speed that would cause mechanical resonance. When a skip reference
parameter is set to 0 that filter is disabled. The skip reference band parameters define the frequency or speed range either side of the programmed
skip reference, over which references are rejected. The actual reject band is therefore twice that programmed in these parameters, the skip reference
parameters defining the centre of the band. When the selected reference is within a band the lower limit of the band is passed through to the ramps
such that reference is always less than demanded.
32
Parameter Parameter
x.00 description format
FI DE Txt VM DP ND RA NC NV
1 1
±SPEED_FREQ_MAX Hz/rpm
0.0
FI DE Txt VM DP ND RA NC NV
1
0.0 to 3,000.0 Hz
0 to 40,000 rpm
0.0
0
FI DE Txt VM DP ND RA NC NV
1
0.0 to 25.0 Hz
0 to 250 rpm
0.5
5
www.controltechniques.com
http://nicontrols.com
Advanced parameter Serial comms
Macros
descriptions
PT US RW BU
1 1
PT US RW BU
1 1
PT US RW BU
1 1
Electronic
Performance
protocol nameplate
PS
PS
1
PS
1
Unidrive SP Advanced User Guide
Issue Number: 7
Feature look-
up table
