Control Techniques unidrive sp Advanced User's Manual page 189

Parameter Keypad and
Menu 11
structure display
11.38 SMARTCARD data type/mode
Drive modes Open-loop, Closed-loop, Servo, Regen
Bit SP
Coding
Range Open-loop, Closed-loop, Servo, Regen
Update rate Background write
Indicates the type/mode of the data block selected with Pr 11.37 as shown in the following table.
Pr 11.38 String
0 FrEE Value when Pr 11.37 = 0
2 3OpEn.LP Open-loop mode parameters
3 3CL.VECt Closed-loop vector mode parameters
4 3SErVO Servo mode parameters
5 3rEgEn Regen mode parameters
6 to 8 3Un Unused
10 4OpEn.LP Open-loop mode parameters
11 4CL.VECt Closed-loop vector mode parameters
12 4SErVO Servo mode parameters
13 4rEgEn Regen mode parameters
14 to 16 4Un Unused
17 LAddEr Drive Onboard PLC program
A file containing user defined data
18 Option (normally created by an SM-Applications
option module)
11.39 SMARTCARD data version
Drive modes Open-loop, Closed-loop, Servo, Regen
Bit SP
Coding
Range Open-loop, Closed-loop, Servo, Regen
Default Open-loop, Closed-loop, Servo, Regen
Update rate Background read/write
Indicates the version number of the data block. This is intended to be used when data blocks are used as drive macros. If a version number is to be
stored with a data block this parameter should be set to the required version number before the data is transferred. Each time Pr 11.37 is changed by
the user the drive puts the version number of the currently viewed data block in this parameter.
11.40 SMARTCARD data checksum
Drive modes Open-loop, Closed-loop, Servo, Regen
Bit SP
Coding
Range Open-loop, Closed-loop, Servo, Regen
Update rate Background write
Gives the checksum of the data block or the bytes left on the card if Pr 11.37 = 1000.
11.41 Status mode time-out
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Bit SP
Coding
Open-loop, Closed-loop vector, Servo,
Range
Regen
Open-loop, Closed-loop vector, Servo,
Default
Regen
Update rate Background read
Sets the timeout for the drive display to revert to status mode from edit mode following no key presses. Although this parameter can be set to less
than 2s, the minimum timeout is 2s.
188
Parameter Parameter
x.00 description format
FI DE Txt VM DP ND
1 1
0 to 18
Type/mode
FI DE Txt VM DP ND
0 to 9,999
0
FI DE Txt VM DP ND
1
0 to 65,335
FI DE Txt VM DP ND
0 to 250 s
240
www.controltechniques.com
http://nicontrols.com
Advanced parameter
Macros
descriptions
RA NC NV PT US RW BU
1 1
Data stored
Data from EEPROM
Data from EEPROM
Data from EEPROM
Data from EEPROM
Defaults last loaded and differences
Defaults last loaded and differences
Defaults last loaded and differences
Defaults last loaded and differences
Drive Onboard PLC program
User defined
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
Serial comms Electronic
Performance
protocol nameplate
PS
1
PS
1
PS
1
PS
1
Unidrive SP Advanced User Guide
Issue Number: 7
Feature look-
up table
