16
MENU SCREEN
■ GPS items (Continued)
GPS Position (Continued)
[MY] screen (MY Position)
Compass* Your direction
Latitude Your latitude
Longitude Your longitude
Shows the grid locator based on the latitude and longitude of
GL
your position.
ALT Your own altitude
SPEED Your speed over ground
TIME Current time received from the GPS
COURSE Your direction heading
When "Manual" is selected in the GPS Select item, the screen shows only latitude,
longitude, altitude, GL (Grid locator), and time (internal clock).
[RX] screen (Received position of the other station)
Depending on the caller's TX mode or TX format, the displayed items and
these meanings differ.
The following lists describe the items in each category.
Nothing is displayed when no position data is received on your transceiver.
1. When the caller's TX mode is NMEA
Compass* Displays the caller's direction from your position.
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on the caller's latitude and
GL
longitude.
ALT Displays the caller's altitude
DST Displays the caller's distance from your position
Call sign Displays the caller's call sign
COURSE Displays the caller's direction over ground
SPEED Displays the caller's speed
GPS Time Stamp Displays the time that the caller acquired the position data.
2. When the caller's TX format is D-PRS Position (Mobile station)
Compass* Displays the caller's direction from your position
Symbol Displays the caller's D-PRS symbol
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on the caller's latitude and
GL
longitude.
ALT Displays the caller's altitude
DST Displays the caller's distance from your position
Call sign Displays the caller's call sign (with SSID)
COURSE Displays the caller's direction over ground
SPEED Displays the caller's speed
GPS Time Stamp Displays the time that the caller acquired the position data.
*These items can be selected in the Quick Menu screen.
16-35
