10
GPS OPERATION
■ Checking GPS Position (Continued)

D TX format: D-PRS Object

The following items are displayed when the caller's TX
format is D-PRS Object.
Displays the Object station's direction
Compass
from your position
Displays the Object station's D-PRS
Symbol
symbol
Latitude Displays the Object station's latitude
Longitude Displays the Object station's longitude
Displays the grid locator based on the
GL
Object station's latitude and longitude.
ALT Displays the Object station's altitude
Displays the Object station's distance
DST
from your position
Object name Displays the Object station's name
Displays the caller's call sign (with
Call sign
SSID)
Displays the Object station's direction
COURSE
over ground
SPEED Displays the Object station's speed
Displays the Object station's TX
POWER
power level
Displays the height of Object station's
HEIGHT
antenna
Displays the gain of Object station's
GAIN
antenna
Displays the direction that the Object
DIRECT
station's antenna was pointing
Displays the time that the caller sent
GPS Time Stamp
the Object station's data.
TIP: When the bject station is disabled, "KILLED"
O
appears.

D TX format: D-PRS Item

The following items are displayed when the caller's TX
format is D-PRS Item.
Compass
Symbol
Latitude
Longitude
GL
ALT
DST
Item name
Call sign
COURSE
SPEED
POWER
HEIGHT
GAIN
DIRECT
TIP: When the Item station is disabled, "KILLED" ap-
pears.
10-8
Displays the Item station's direction
from your position
Displays the Item station's D-PRS
symbol
Displays the Item station's latitude
Displays the Item station's longitude
Displays the grid locator based on the
Item station's latitude and longitude.
Displays the Item station's altitude
Displays the Item station's distance
from your position
Displays the Item station's name
Displays the caller's call sign (with
SSID)
Displays the Item station's direction
over ground
Displays the Item station's speed
Displays the Item station's TX power
level
Displays the height of Item station's
antenna
Displays the gain of Item station's an-
tenna
Displays the direction that the Item
station's antenna was pointing
