17
OTHER FUNCTIONS
■ Cloning function (Continued)

D Cloning from a PC using a microSD card

The cloning can be performed from a PC using a mi-
croSD card.
Set a desired memory channels, MENU item settings
and Repeater List by the CS-51PLUS2 cloning soft-
ware (contained in the CD), and save them in an "icf"
file format. Copy the "icf" file into the "Setting" folder in
the "ID-51" folder of the microSD card.
• microSD card configuration
Attach the microSD card that includes the "icf" file, then
load it to complete the cloning.
Csv
Gps
QsoLog
ID-51
Reply
RxLog
Setting
Voice
VoiceRec
VoiceTx

D Cloning from a PC using an optional data cable

Cloning can be performed using the CS-51PLUS2
(contained in the CD) and the optional data communi-
cation cable.
See the CS-51PLUS2 instruction manual contained in
the CD and the data communication cable's instruction
manual (downloaded from the Icom WEB site; http://www.
icom.co.jp/world/).
• Connections
"Clone Mode"
To the [DATA] jack
Transceiver
GpsMemory
RptList
YourMemory
yyyymmdd
yyyymmdd
yyyymmdd
yyyymmdd
CS-51PLUS2
OPC-2218LU (Option)
OPC-2350LU (Option)
PC
To a [USB] port
• Connections
CS-51PLUS2
Or
Card reader
NOTE: When using the optional data communica-
tion cable
• Before cloning, select "PTT" option in DV Data TX
item. If "Auto" is selected, the transceiver may trans-
mit with the cloning data.
(DV Set > DV Data TX)
• Before cloning, select the Clone mode in the MENU
screen.
(Other > Clone Mode)
17-20
CS-51PLUS2
Click
Click
Click
Copy the
"icf" file.
