5.7.2

SATA Power

The conga-IA3 provides an internal SATA power for hard drives on connector X8. This connector supplies 3.3V, 5V and 12V.
Connectors X8 Pinout Description.
Pin Signal
1 +3.3V
2 +3.3V
3 +3.3V
4 GND
5 GND
6 GND
7 +5V
8 +5V
Connector Type
X8: 15 Pos. SATA Connector.
Note
The voltage rails +3.3V, +5V and +12V have maximum current of 2 amps each.
5.7.3

Mini SATA

The mini SATA connector X6 on the conga-IA3 is used to connect mSATA devices. This connector also supports mini PCIe devices. When an
mSATA or mPCIe device is connected to X6, the conga-IA3 automatically detects the type of device that is attached.
mSATA (Connector X6) Pin Description.
Pin Signal
1 Reserved
3 N.C.
5 N.C.
7 Reserved
Copyright © 2015 congatec AG
Pin Signal
9 +5V
10 GND
11 GND
12 GND
13 12V
14 12V
15 12V
Pin Signal
2 +3.3V
4 GND
6 +1.5V
8 N.C.
SATA Power (X8)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
