8.4.7

ACPI Submenu

Feature
Enable ACPI Auto
Configuration
Enable Hibernation
ACPI Sleep State
Lock Legacy Resources
LID Support
Sleep Button Support
8.4.8

SIO Submenu

Feature
Super IO Chip
►Serial Port 1
►Serial Port 2
8.4.8.1

Serial Port 1 Submenu

Feature
Use this Device
Logical Device Settings
Possible
Copyright © 2015 congatec AG
Options Description
Disabled Enable or disable BIOS ACPI Auto Configuration
Enabled
Disabled Enable or disable system's ability to hibernate (operating system S4 sleep state). This option may not be
Enabled
effective with some operating systems.
Suspend Disabled Select the state used for ACPI system sleep/suspend.
S3 (Suspend to RAM)
Disabled Enable or disable locking of legacy resources.
Enabled
Disabled Configure COM Express LID# Signal to act as a ACPI lid.
Enabled
Disabled Configure COM Express SLEEP# Signal to act as a ACPI sleep button.
Enabled
Options Description
NCT6791D
No option Serial Port 1 submenu
No option Serial Port 2 submenu
Options
Enable
Disable
No option
Use Automatic Settings
IO=3F8; IRQ=3,4,5,7,9,10,11, 12; DMA;
IO=2F8; IRQ=3,4,5,7,9,10,11, 12; DMA;
IO=3F8; IRQ=3,4,5,7,9,10,11, 12; DMA;
IO=3E8; IRQ=3,4,5,7,9,10,11, 12; DMA;
Description
Enable logical device
Show current logical device settings
Serial Port 1 configurations options
