Feature
PAVC
8.5.2

South Bridge Submenu

Feature

►Azalia HD Audio

► USB
► PCI Express Configuration
High Precision Timer
Serial IRQ
Global SMI Lock
BIOS Read/Write Protection
Isolate SMBus Segments
8.5.2.1 Azalia HD Audio
Feature
LPE Audio Support
Audio Controller
Azalia Vci Enable
Azalia Docking Support Enable
Azalia PME Enable
Azalia HDMI Codec
HDMI Port B
Copyright © 2015 congatec AG
Options Description
Enable Enable/Disable Protected Audio Video Control
Disable
Options Description
Submenu Azalia HD Audio Submenu.
Submenu USB Submenu.
Submenu PCI Express Configuration Submenu.
Enabled Enable High Precision Event Timer.
Disabled
Quiet Configure IRQ Serial Mode
Continuous
Enabled Enable or Disable SMI Lock
Disabled
Enabled Enable BIOS SPI Region read/write protection.
Disabled
Never Allows isolating the off-module/external SMBus segment from the on-module SMBus segment. This can
During POST be a workaround for non spec conform external SMBus devices.
Always
Options Description
Disable Enable LPE Audio Support.
LPE Audio PCI Mode
LPE Audio ACPI Mode
Enabled Enable Audio Controller.
Disabled
Enabled Enable Azalia Vci.
Disabled
Enable Enable Azalia Docking support.
Disable
Enabled Enable Azalia PME support.
Disabled
Enabled Enable Azalia HDMI Codec
Disabled
Enabled Enable HDMI Port B Audio.
Disabled
IA30m10 74/82
