1.2.1

Options Information

The conga-IA3 is currently available in four variants.
configurations available. Check for the Part No. that applies to your product. This will tell you what options described in this user's guide are
available on your particular module
conga-IA3
Part-No.
Processor
L2 Cache
Burst Frequency
Memory (DDR3L)
Processor Graphics
Graphics Base/Burst Freq.
VGA
LVDS
DDI
Processor TDP (Max)
* Scenario Design Power (SDP) of 4.5W
1.2.2

Optional Accessories/Cables

Accessories
conga-IA30/CSP
conga-IA30/Retention Frame
conga-IA30/IO Bracket Standard Size
conga-IA30/IO Bracket Thin Size
DDR3L-SODIMM-1600 (2 GB)
DDR3L-SODIMM-1600 (4 GB)
DDR3L-SODIMM-1600 (8 GB)
Copyright © 2015 congatec AG
This user's guide describes all of these variants. The tables below show the different
052300 052301
Intel Atom™ E3845 1.91 GHz Intel
® ®
Quad Core™
2 MByte
N/A
1333 MT/s dual channel 1066 MT/s dual channel
Intel HD Graphics (GT1) Intel
®
542 / 792 MHz
No
Single/Dual 18/24bit
DP / HDMI / DVI
10 W
Part No. Description
052351 Passive cooling solution with Thin Mini-ITX height (for conga-IA3)
052355 Retention frame for conga-IA3 standard cooling
052356 IO shield for conga-IA3 with Mini-ITX height
052357 IO shield for conga-IA3 with Thin Mini-ITX height
068755 Certified 2 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
068756 Certified 4 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
068757 Certified 8 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
052310
Atom™ E3826 1.46 GHz Intel Celeron™ J1900 2.0 GHz
®
Dual Core™ Quad Core™
1 MByte
N/A 2.41 GHz
1333 MT/s dual channel
HD Graphics (GT1) Intel HD Graphics (GT1)
® ®
533 / 667 MHz 688 / 854 MHz
No
Single/Dual 18/24bit Single/Dual 18/24bit
DP / HDMI / DVI DP / HDMI / DVI
7 W
IA30m10
052311
Intel Celeron™ N2930 1.83 GHz
®
Quad Core™
2 MByte 2 MByte
2.16 GHz
1333 MT/s dual channel
Intel HD Graphics (GT1)
®
313 / 854 MHz
No No
Single/Dual 18/24bit
DP / HDMI / DVI
10 W 7.5 W *
