Hardware Health Monitoring Submenu - Congatec conga-IA3 User Manual

Feature
Force LVDS Backlight
Inhibit Backlight
LVDS SSC
8.4.3

Hardware Health Monitoring Submenu

Feature
CPU Temperature
Board Temperature
TS AMBIENT DXP
DIMM DXP
3.3V Standard
5V Standby
12V Standard
VCORE
System Fan Speed
CPU Fan Speed
System Fan Mode
System Fan PWM Speed
Setting
CPU Fan Speed Mode
Minimum Fan Speed
Copyright © 2015 congatec AG
Options Description
No Force LVDS Enable and LVDS VDD Signals unconditionally
Yes
No Decide whether the backlight on signal should be activated when the panel is activated or whether it should
Permanent remain inhibited until the end of BIOS POST or permanently.
Until End Of POST
Disabled
Configures LVDS Spread Spectrum Clock Modulation (SSC) depth. It uses center spreading and a fixed
Enabled modulation frequency of 32.9khz.
Options Description
No option Displays the actual CPU Temperature in °C.
No option Displays the actual module board temperature in °C.
No option Displays the actual module environment temperature in °C.
No option Displays the actual module DIMM DXP Temperature in °C.
No option Displays the actual voltage of the 3.3V standard power supply.
No option Displays the actual voltage of the 5V standby power supply.
No option Displays the actual voltage of the 12V standard power supply.
No option Displays the actual voltage of the VCORE power supply.
No option Displays the actual System Fan Speed in RPM.
No option Displays the actual CPU Fan Speed in RPM.
Smart Mode Configures the System Fan Mode
PWM Mode
0%, 10%, 20%, 30%, 40%, Select minimum/start fan speed to be set when the start temperature of the control slope is reached.
50%, 60%, 70%, 80%, 90%,
100%
Smart Mode Configures the CPU Fan Speed Mode
PWM Mode
0%, 10%, 20%, 30%, 40%, Select minimum/start fan speed to be set when the start temperature of the control slope is reached.
50%, 60%, 70%, 80%, 90%,
100%
