Feature
HDMI Port C
8.5.2.2

USB Submenu

Feature
USB OTG Support
USB VBUS
XHCI Mode
USB2 Link Power
Management
USB 2.0(EHCI) Support
USB Per Port Control
USB Port 0
USB Port 1
USB Port 2
USB Port 3
Copyright © 2015 congatec AG
Options Description
Enabled Enable HDMI Port C Audio.
Disabled
Options Description
Disabled Enable USB OTG support.
Enabled
On VBUS should be On in Host Mode and it should be Off in OTG device Mode.
Off
Enabled USB3.0 mode support on USB0, USB1, USB2 and USB3 ports
Disabled
Auto Disabled – USB ports will function in USB2.0 mode only. No USB3.0 OS driver required. The USB ports will be
Smart Auto
routed to EHCI1 controller.
Enabled – USB ports will function correctly in BIOS but the ports on which the USB3.0 mode is enabled (see USB0
port USB3.0 item) will not function at all under OS if the USB3.0 OS driver is not installed. USB ports will not
function in pre-OS time if USB3.0 Support in BIOS is disabled (see the USB3.0 Support in BIOS item).
Auto – USB ports are initially set to operate in USB2.0 Mode and the USB3.0 OS driver (if available) will switch
them USB3.0 mode. If USB3.0 OS driver is not available than the ports will function correctly but they will operate in
USB2.0 mode.
Smart Auto – The BIOS will store the USB mode set by the OS and at next boot the BIOS will set this previously
used mode. At G3 boot (first boot after mechanical disconnection of the power supply) the USB ports will function
identically as in Auto mode. This mode is not available when Disabled is selected at USB3.0 Support in BIOS item.
Disabled Enable USB2 Link Power Management
Enabled
Disabled Control USB EHCI (USB 2.0) functions.
Enabled
Disabled Control each of the USB ports (0-3).
Enabled
Disabled Enable Port 0
Enabled
Disabled Enable Port 1
Enabled
Disabled Enable Port 2
Enabled
Disabled Enable Port 3
Enabled
IA30m10 75/82
