6.8

API Support (CGOS)

In order to benefit from the above mentioned non-industry standard feature set, congatec provides an API that allows application software
developers to easily integrate all these features into their code. The CGOS API (congatec Operating System Application Programming
Interface) is the congatec proprietary API that is available for all commonly used Operating Systems such as Win32, Win64, Win CE, Linux.
The architecture of the CGOS API driver provides the ability to write application software that runs unmodified on all congatec CPU modules.
All the hardware related code is contained within the congatec embedded BIOS on the module. See section 1.1 of the CGOS API software
developers guide, which is available on the congatec website .
6.9

GPIOs

The conga-IA3 SBC provides eight General Purpose Inputs via the congatec board controller and eight General Purpose Outputs via the
onboard Super I/O. The GPIO signals are routed to the feature connector X34.
6.10

Thermal/Voltage Monitoring

The conga-IA3 SBC features three temperature sensors - the CPU, memory and board controller sensors.
The board controller can monitor six different voltages which are main power, 5V (runtime), 5V (standby), 1.05V (runtime), VCORE, 3,3V (runtime)
and 3,3V (standby).
6.11

Beeper

The board-mounted speaker (M10) provides audible error code (beep code) information during POST.
6.12

External System Wake Event

The conga-IA3 supports LAN, USB, PCIe and PWRBTN driven wake up events.
Copyright © 2015 congatec AG
PC Beeper
(M10)
