SATA Connectors
The conga-SMC1 provides a standard SATA 3.0 port and a SATA power header.
4.8.1
Standard SATA Port
The conga-SMC1 provides a standard SATA port via connector X5. The port supports SATA, SATADOM pin 7 or SATADOM pin 8 devices. The
maximum output current for a SATADOM device is 500 mA. For SATADOM devices, use jumper X7 to configure the power source (pin 7 or 8).
To show SATA port activity, connect an LED to pin 11 and 12 of the front panel connector X32.
Table 18
X7 Pinout Description
Jumper
SATADOM Power Source
1-2
SATADOM Pin 8 (default)
2-3
SATADOM Pin 7
Connector Type
X5: Standard SATA cable
4.8.2
SATA Power Connector
The conga-SMC1 provides a 4-pin SATA power connector X8 for HDD or SSD.
Table 19
X8 Pinout Description
Pin Signal
1
+5 V (1.5 A fuse)
2
GND
3
GND
4
+12 V (1.5 A fuse)
Connector Type
X8: 2.5 mm pitch, 4-pin header (TE 171825-4) )
Possible Mating Connector: TE 171822-4
Copyright © 2020 congatec AG
X7
1
2
3
SMC1m10
X5
7 6 5 4 3
2 1
X8
36/50
