8.4.25.1

NIC Configuration Submenu

Feature
Link Speed
Wake on LAN
8.4.26

Driver Health Submenu

Feature
► Intel(R) PRO/1000
8.4.26.1

Intel(R) PRO/1000 Submenu

Feature
Controller Information
8.5

Chipset Setup

Select the Boot tab from the setup menu to enter the Boot setup screen.
8.5.1

North Bridge Submenu

Feature
Memory Information
Total Memory
Memory Slot 0
Memory Slot 1
Max TOLUD
Aperture Size
Copyright © 2015 congatec AG
Options Description
Auto Negotiated Specifies the port speed used for the selected boot protocol.
10 Mbps Half
10 Mbps Full
100 Mbps Half
100 Mbps Full
Disabled Enables Wake on LAN (WOL) feature
Enabled
Options Description
No option Provides Health Status for the drivers/Controllers connected to the System
Options Description
No option Provides Health Status of the controller
Options Description
No option Total amount of memory detected by the system
No option Memory detected by the system on Slot 0
No option Memory detected by the system on Slot 1
Dynamic, 2 GB, 2.25 GB, Maximum value of TOLUD Dynamic assignment would adjust TOLUD automatically based on largest
2.5 GB, 2.75 GB, 3 GB, MMIO length of installed graphic controller.
128MB Select Aperture Size
256MB
512MB
IA30m10 73/82
