8.4.1

Watchdog Submenu

Feature Options
Disabled
POST Watchdog
30sec
1min
2min
5min
10min
30min
Stop Watchdog for No
Yes
User Interaction
Runtime Watchdog Disabled
One-time Trigger
Single Event
Repeated Event
Delay Disabled
10sec
30sec
1min
2min
5min
10min
30min
Event 1 ACPI Event
Reset
Power Button
Event 2 Disabled
ACPI Event
Reset
Power Button
Event 3 Disabled
ACPI Event
Reset
Power Button
Copyright © 2015 congatec AG
Description
Select the timeout value for the POST watchdog.
The watchdog is only active during the power-on-self-test of the system and provides a facility to prevent errors during boot
up by performing a reset.
Select whether the POST watchdog should be stopped during the popup of the boot selection menu or while waiting for
setup password insertion.
Select the operating mode of the runtime watchdog. This watchdog will be initialized just before the operating system starts
booting.
If set to 'One-time Trigger' the watchdog will be disabled after the first trigger.
If set to 'Single Event', every stage will be executed only once, then the watchdog will be disabled.
If set to 'Repeated Event' the last stage will be executed repeatedly until a reset occurs.
Select the delay time before the runtime watchdog becomes active. This ensures that an operating system has enough time
to load.
Select the type of event that will be generated when timeout 1 is reached. For more information about ACPI Event, see note
below.
Select the type of event that will be generated when timeout 2 is reached.
Select the type of event that will be generated when timeout 3 is reached.
IA30m10 55/82
