8.5.2.3

PCI Express Configuration Submenu

Feature
PCIe noncompliance Card
PCI Express Port 0/1/2/3
ASPM
Hot Plug
Speed
Extra Bus Reserved
Reserved Memory
Prefetchable Memory
Reserved I/O
8.6

Boot Setup

Select the Boot tab from the setup menu to enter the Boot setup screen.
8.6.1

Boot Settings Configuration

Feature
Setup Prompt Timeout
Bootup NumLock State
Quiet Boot
Copyright © 2015 congatec AG
Options
Description
Not Supported
Enable PCIe 1.0 Device Support
Supported
Disabled
Enable PCIe Port 0/1/2/3.
Enabled
Disabled
PCI Express Active State Power Management settings.
L0s
L1
L0sL1
Auto
Disabled
Select hot plug support for PCIe Port
Enabled
Auto
Configure PCIe Port 0/1/2/3 Speed.
Gen 2
This feature is visible only if PCIe noncompliance card option is set to "Not Supported". If the option is set to
Gen 1
"supported", then the speed defaults to Gen 1.
0-7
Extra bus reserved (0-7) for bridges behind this root bridge.
Default : 0
1-20
Reserved memory range for this root bridge.
Default : 10
1-20
Prefetchable memory range for this root bridge.
Default : 10
0-20
Reserved I/O range for this root bridge.
Default : 4
Options
Description
1
Number of seconds to wait for setup activation key.
0 - 65535
0 means no wait for fastest boot (not recommended), 65535 means infinite wait.
On
Select the keyboard numlock state.
Off
Disabled
Disabled displays normal POST diagnostic messages.
Enabled
Enabled displays OEM logo instead of POST messages.
Note: The default OEM logo is a dark screen.
IA30m10
76/82
