Congatec conga-IA3 User Manual page 56

Feature Options
Timeout 1 1sec
2sec
5sec
10sec
30sec
1min
2min
5min
10min
30min
Timeout 2 See above
Timeout 3 See above
Watchdog ACPI Shutdown
Event Restart
Note
In ACPI mode, it is not possible for a "Watchdog ACPI Event" handler to directly restart or shutdown the OS. For this reason the congatec
BIOS will do one of the following:
For Shutdown: An over temperature notification is executed. This causes the OS to shut down in an orderly fashion.
For Restart: An ACPI fatal error is reported to the OS.
Copyright © 2015 congatec AG
Description
Select the timeout value for the first stage watchdog event.
Select the timeout value for the second stage watchdog event.
Select the timeout value for the third stage watchdog event.
Select the operating system event that is initiated by the watchdog ACPI event. These options perform a critical but orderly
operating system shutdown or restart.
IA30m10 56/82
